making your home smarter use case #13 – correlations happen

There are a lot of things that happen in the smart house that are connected somehow.

And the smart house knows about those events happening and might suggest, or even act upon the knowledge of them.

A simple example:

In our living room we’ve got a nice big aquarium which, depending on the time of the day and season, it is simulating it’s very own little dusk-till-dawn lightshow for the pleasure of the inhabitants.
Additionally the waterquality is improved by an air-pump generating nice bubbles and enriching the water with oxygen. But that comes a cost: When you are in the room those bubbles and the hissing sound of the inverter for the “sun” produces sounds that are distracting and disturbing to the otherwise quiet room.

Now the smart home comes to the rescue:

It detects that whenever someone is entering the room and staying for longer, or powering up the TV or listening to music. Also it will log that regularly when these things happen also the aquarium air and maybe lights are turned off. Moreso they are turned back on again when the person leaves.

These correlations are what the smart house is using to identify groups of switches, events and actions that are somehow tied together. It’ll prepare a report and will recommend actions which at the push of a button can become a routine task always being executed when certain characteristics are lining up.

And since the smart house is a machine, it can look for correlations in a lot more dimensions a human could: Date, Time, Location, Duration, Sensor and Actor values (power up TV, Temperature in room < 22, Calendar = November, Windows closed => turn on the heating).

No Comments

“making your home smarter” – use case #12 – How much time do I have until…?

Did you notice that most calendars and timers are missing an important feature. Some information that I personally find most interesting to have readily available.

It’s the information about how much time is left until the next appointment is coming up. Even smartwatches, which should should be jack-of-all-trades in regards of time and schedule, do not display the “time until the next event”.

Now I came across this shortcoming when I started to look for this information. No digital assistant can tell me right away how much time until a certain event is left.

But the connected house also is based upon open technologies, so one can add these kind of features easily ourselves. My major use cases for this are (a) focussed work, plan quick work-out breaks and of course making sure there’s enough time left to actually get enough sleep.

As you can see in the picture attached my watch will always show me the hours (or minutes) left until the next event. I use separate calendars for separate displays – so there’s actually one for when I plan to get up and do work-outs.

Having the hours left until something is supposed to happen at a glance – and of course being able to verbally ask through chat or voice in any room of the house how long until the next appointment gives peace of mind :-).



No Comments

“making your home smarter”, use case #10 – Fire and Water alarm system

Water! Fire! Whenever one of those are released uncontrolled inside the house it might mean danger to life and health.

Having a couple of fish and turtle tanks spread out in the house and in addition a server rack in the basement it’s important to know when there’s a leak of water at moments notice.

As the server-room also is housing some water pumps for a well you got all sorts of dangers mixed in one location: Water and Fire hazard.

To detect water leaks all tanks and the pumps for the well are equipped with water sensors which send out an alerting signal as soon as water is detected. This signal is picked up and pushed to MQTT topics and from there centrally consumed and reacted upon.

Of course the server rack is above the water level so at least there is time to send out alerts while even power is out for the rest of the house (all necessary network and uplink equipment on it’s own batteries).

For alerting when there is smoke or a fire, the same logic applies. But for this some loud-as-hell smoke detectors are used. The smoke detectors interconnect with each other and make up a mesh for alerting. If one goes off. All go off. One of them I’ve connected to it’s very own ESP8266 which sends a detected signal to another MQTT topic effectively alerting for the event of a fire.

In one of the pictures you can see what happened when the basement water detector did detect water while the pump was replaced.

No Comments

“making your home smarter”, use case #9 – weights about to drop

A lot of things in a household have weight, and knowing it’s weight might be crucial to health and safety.

Some of those weight applications might tie into this:

– your own body weight over a longer timespan
– the weight of your pets, weighed automatically (like on a kitty litter box)
– the weight of food and ingredients for recipes as well as their caloric and nutrition values
– keeping track of fill-levels on the base of weights

All those things are easily done with connected devices measuring weights. Like the kitty-litter box at our house weighing our cat every time. Or the connected kitchen-scale sending it’s gram measurements into an internal MQTT topic which is then displayed and added more smarts through an App on the kitchen-ipad consuming that MQTT messages as well as allowing recipe-weigh-in functions.

It’s not only surveillance but pro-active use. There are beekeepers who monitor the weight of their bee hives to see what’s what. You can monitor all sorts of things in the garden to get more information about it’s wellbeing (any plants, really).

No Comments

“making your home smarter”, use case #8 – it’s all about the power consumption

Weekend is laundry time! The smart house knows and sends out notifications when the washing machine or the laundry dryer are done with their job and can be cleared.

Of course this can all be extended with more sensory data, like power consumption measurements at the actual sockets to filter out specific devices much more accurate. But for simple notification-alerting it’s apparently sufficient to monitor just at the houses central power distribution rack.

On the sides this kind of monitoring and pattern-matching is also useful to identify devices going bad. Think of monitoring the power consumption of a fridge. When it’s compressor goes bad it’s going to consume an increasing amount of power over time. You would figure out the malfunction before it happens.

Same for all sorts of pumps (water, oil, aquarium,…).

All this monitoring and pattern matching the smart house does so it’s inhabitants don’t have to.

No Comments

“make your home smarter”, use case #7 – hear that doorbell ringing!

We love music. We love it playing loud across the house. And when we did that in the past we missed some things happening around.

Like that delivery guy ringing the front doorbell and us missing an important delivery.

This happened a lot. UNTIL we retrofitted a little PCB to our doorbell circuit to make the house aware of ringing doorbells.

Now everytime the doorbell rings a couple of things can take place.

– push notifications to all devices, screens, watches – that wakes you up even while doing workouts
– pause all audio and video playback in the house
– take a camera shot of who is in front of the door pushing the doorbell

And: It’s easy to wire up things whatever those may be in the future.

No Comments

“make your home smarter”, use case #5 – the submarine light (it’s red!)

We all know it: After a long day of work you chilled out on your bean bag and fell asleep early. You gotta get up and into your bed upstairs. So usually light goes on, you go upstairs, into bed. And there you have it: You’re not sleepy anymore.

Partially this is caused by the light you turned on. If that light is bright enough and has the right color it will wake you up no matter what.

To fight this companies like Apple introduced things like “NightShift” into iPhones, iPads and Macs.

“Night Shift uses your computer’s clock and geolocation to determine when it’s sunset in your location. It then automatically shifts the colors in your display to the warmer end of the spectrum.”

Simple, eh?. Now why does your house not do that to prevent you being ripped out of sleepy state while tiptoeing upstairs?

Right! This is where the smart house will be smart.

Nowadays we’ve got all those funky LED bulbs that can be dimmed and even their colours set. Why none of those market offerings come with that simple feature is beyond me:

After sunset, when turned on, default dim to something warmer and not so bright in general.

I did implement and it’s called appropriately the “U-Boot light”. Whenever we roam around the upper floor at night time, the light that follows our steps (it’s smart enough to do that) will not go full-blast but light up dim with redish color to prevent wake-up-calls.

The smart part being that it will take into account:

– movement in the house
– sunset and dawn depending on the current geographic location of the house (more on that later, no it does not fly! (yet))
– it’ll turn on and off the light according to the path you’re walking using the various sensors around anyways

No Comments

smart home use case #4 – being location aware is important

Now that you got your home entertainment reacting to you making a phone call (use case #1) as well as your current position in the played audiobook (use case #3) you might want to add some more location awareness to your house.

If your house is smart enough to know where you are, outside, inside, in what room, etc. – it might as well react on the spot.

So when you leave/enter the house:

– turn off music playing – pause it and resume when you come back
– shutdown unnecessary equipment to limit power consumption when not used and start-back up to the previous state (tvs, media centers, lights, heating) when back
– arm the cameras and motion sensors
– start to run bandwidth intense tasks when no people using resources inside the house (like backing up machines, running updates)
– let the roomba do it’s thing
– switch communication coming from the house into different states since it’s different for notifications, managing lists and spoken commands and so on.

There’s a lot of things that that benefit from location awareness.

Bonus points for outside house awareness and representing that like a “Weasly clock”…“xxx is currently at work”.

Bonus points combo breaker for using an open-source service like Miataru (http://miataru.com/#tabr3) for location tracking outside the house.

No Comments

carbon neutral house – when the sun is shining.

7 day and 30 day graphs for solar power generation, power consumption, oil burn to heat water and outside temperatures to go along with.

Having everything in a time-series-database makes such things a real blast… data wandering around all the telemetry. There are almost 300 topics to pick from and combine.

Yes, generally the solar array produces more than the whole household consumes. Except that one 26th.

Thinking about building a display showing when we are closing in to consume what has been produced in terms of electricity… something like a traffic light getting more red towards the use-up of electricity generated carbon-neutral.

No Comments

How to weigh your cat! – the IoT version

This is Leela. She is a 7 year old lilac white British short hair cat that lives with us. Leela had a sister who used to live with us as well but she developed a heart condition and passed away last year. Witnessing how quickly such conditions develop and evaluate we thought that we can do something to monitor Leelas health a bit to just have some sort of pre-alert if something is changing.

Kid in a Candystore

As this Internet of Things is becoming a real thing these days I found myself in a candy store when I’ve encountered that there are a couple of really really cheap options to get a small PCB with input/output connectors into my house WiFi network.

One of the main actors of this story is the so called ESP8266. A very small and affordable system-on-a-chip that allows you to run small code portions and connect itself to a wireless network. Even better it comes with several inputs that can be used to do all sorts of wonderful things.

And so it happened that we needed to know the weight of our cat. She seemed to get a bit chubby over time and having a point of reference weight would help to get her back in shape. If you every tried to weigh a cat you know that it’s much easier said than done.

The alternative was quickly brought up: Build a WiFi-connected scale to weigh her litter box every time she is using it. And since I’ve recently bought an evaluation ESP8266 I just had to figure out how to build a scale. Looking around the house I’ve found a broken human scale (electronics fried). Maybe it could be salvaged as a part donor?

A day later I’ve done all the reading on that there is a thing called “load-cell”. Those load cells can be bought in different shapes and sizes and – when connected to a small ADC they deliver – well – a weight value.

I cracked the human scale open and tried to see what was broken. It luckily turned out to have completely fried electronics but the load-cells where good to go.

Look at this load cell:

Hardware

That brought down the part list of this project to:

  • an ESP8266 – an Adafruit Huzzah in my case
  • a HX711 ADC board to amplify and prepare the signal from the load-cells
  • a human scale with just enough space in the original case to fit the new electronics into and connect everything.

The HX711 board was the only thing I had to order hardware wise – delivered the next day and it was a matter of soldering things together and throwing in a small Arduino IDE sketch.

My soldering and wiring skills are really sub-par. But it worked from the get-go. I was able to set-up a small Arduino sketch and get measurements from the load-cells that seemed reasonable.

Now the hardware was all done – almost too easy. The software would be the important part now. In order to create something flexible I needed to make an important decision: How would the scale tell the world about it’s findings?

Software

Two basic options: PULL or PUSH?

Pull would mean that the ESP8266 would offer a webservice or at least web-server that exposes the measurements in one way or the other. It would mean that a client needs to poll for a new number in regular intervals.

Push would mean that the ESP8266 would connect to a server somewhere and whenever there’s a meaningful measurement done it would send that out to the server. With this option there would be another decision of which technology to use to push the data out.

Now a bit of history: At that time I was just about to re-implement the whole house home automation system I was using for the last 6 years with some more modern/interoperable technologies. For that project I’ve made the decision to have all events (actors and sensors) as well as some additional information being channeled into MQTT topics.

Let’s refer to Wikipedia on this:

“MQTT1 (formerly MQ Telemetry Transport) is an ISO standard (ISO/IEC PRF 20922) publish-subscribe-based “lightweight” messaging protocol for use on top of the TCP/IP protocol. It is designed for connections with remote locations where a “small code footprint” is required or the network bandwidth is limited. The publish-subscribe messaging pattern requires a message broker. Thebroker is responsible for distributing messages to interested clients based on the topic of a message. Andy Stanford-Clark and Arlen Nipper of Cirrus Link Solutions authored the first version of the protocol in 1999.”

Something build for oil-pipelines can’t be wrong for your house – can it?

So MQTT uses the notation of a “topic” to sub-address different entities within it’s network. Think of a topic as just a simple address like “house/litterbox/weight”. And with that topic MQTT allows you to set a value as well.

The alternative to MQTT would have been things like WebSockets to push events out to clients. The decision for the home-automation was done towards MQTT and so far it seems to have been the right call. More and more products and projects available are also focussing on using MQTT as their main message transport.

For the home automation I had already set-up a demo MQTT broker in the house – and so naturally the first call for the litterbox project was to utilize that.

The folks of Adafruit provide the MQTT library with their hardware and within minutes the scale started to send it’s measurements into the “house/litterbox/weight” topic of the house MQTT broker.

Some tweaking and hacking later the litterbox was put together and the actual litterbox set on-top.

Since Adafruit offers platform to also send MQTT messages towards and create neat little dashboards I have set-up a little demo dashboard that shows a selection of data being pushed from the house MQTT broker to the Adafruit.io MQTT broker.

These are the raw values which are sent into the weight topic:

You can access it here: https://io.adafruit.com/bietiekay/stappenbach

So the implementation done and used now is very simple. On start-up the ESP8622 initialises and resets the weight to 0. It’ll then do frequent weight measurements at the rate it’s configured in the source code. Those weight measurements are being monitored for certain criteria: If there’s a sudden increase it is assumed that “the cat entered the litterbox”. The weight is then monitored and averaged over time. When there’s a sudden drop of weight below a threshold that last “high” measurement is taken as the actual cat weight and sent out to a /weight topic on MQTT. The regular measurements are sent separately to also a configurable MQTT topic.

You can grab the very ugly source code of the Arduino sketch here: litterbox_sourcecode

And off course with a bit of logic this would be the calculated weight topic:

Of course it is not enough to just send data into MQTT topics and be done with it. Of course you want things like logging and data storage. Eventually we also wanted to get some sort of notification when states change or a measurement was taken.

MQTT, the cloud and self-hosted

Since MQTT is enabling a lot of scenarios to implement such actions I am going to touch just the two we are using for our house.

  1. We wanted to get a push notification to our phones whenever a weight measurement was taken – essentially whenever the cat has done something in the litterbox. The easiest solution: Set-Up a recipe on If This Than That (IFTTT) and use PushOver to send out push notifications to whatever device we want.
  2. To log and monitor in some sort of a dashboard the easiest solution seemed to be Adafruits offer. Of course hosted inside our house a combination of InfluxDB to store, Telegraf to gather and insert into InfluxDB and Chronograf to render nice graphs was the best choice.

Since most of the above can be done in the cloud (as of: outside the house with MQTT being the channel out) or inside the house with everything self-hosted. Some additional articles will cover these topics on this blog later.

There’s lots of opportunity to add more logic but as far as our experiments and requirements go we are happy with the results so far – we now regularly get a weight and the added information of how often the cat is using her litterbox. Especially for some medical conditions this is quite interesting and important information to have.

No Comments

I wish there was: cheap network microphones with open source speech recognition

I was on a business trip the other day and the office space of that company was very very nice. So nice that they had all sorts of automation going on to help the people.

For example when you would run into a room where there’s no light the system would light up the room for you when it senses your presence. Very nice!

There was some lag between me entering the room, being detected and the light powering up. So while running into a dark room, knowing I would be detected and soon there would be light, I shouted “Computer! Light!” while running in.

That StarTrek reference brought an old idea back that it would be so nice to be able to control things through omnipresent speech recognition.

I am aware that there’s Siri, Cortana, Google Now. But those things are creepy because they involve external companies. If there are things listening to me all day every day, I want them to be within the premise of the house. I want to know exactly down to the data flow what is going on and sent where. I do not want to have this stuff leave the house at any times. Apart from that those services are working okayish but well…

Let alone the hardware. Usually the existing assistants are carried around in smart phones and such. Very nice if you want to touch things prior to talking to them. I don’t want to. And no, “Hey Siri!” or “OK Google” is not really what I mean. Those things are not sophisticated enough yet. I was using “Hey Siri!” for less than 24 hours. Because in the first night it seemed to have picked up something going on while I was sleeping which made it go full volume “How can I help!” on me. Yes, there’s no “don’t listen when I am sleeping” thing. Oh it does not know when I am sleeping. Well, you see: Why not?

Anyway. What I wish there was:

  • cheap hardware – a microphone(-array) possibly to put into every room. It either needs to have WiFi or LAN. Something that connects it to the network. A device that is carried around is not enough.
  • open source speech recognition – everything that is collected by the microphone is processed through an open source speech recognition tool. Full text dictation is a bonus, more importantly heavy-duty command recognition and simple interactions.
  • open source text to speech – to answer back, if wanted

And all that should be working on a basic level without internet access. Just like that.

So? Any volunteers?

1 Comment

when you’re working late: grant your eyes a rest

“Ever notice how people texting at night have that eerie blue glow?

Or wake up ready to write down the Next Great Idea, and get blinded by your computer screen?

During the day, computer screens look good—they’re designed to look like the sun. But, at 9PM, 10PM, or 3AM, you probably shouldn’t be looking at the sun.

f.lux fixes this: it makes the color of your computer’s display adapt to the time of day, warm at night and like sunlight during the day.

It’s even possible that you’re staying up too late because of your computer. You could use f.lux because it makes you sleep better, or you could just use it just because it makes your computer look better.”

Bildschirmfoto 2014-09-27 um 12.58.33

Source: https://justgetflux.com/

No Comments

When your VU+ DUO just shows a red light and does not start up

So it happened to one of the VU+ Duos in the house. After a clean shutdown it did not boot up as expected but instead just showed the red light. It still blinked on remote keypresses and the harddisk spun up. Nothing else happened with it.

So it was bricked.

Reading the forums about that pointed to a capacitor on the board that quite regularly seems to fail. C807 is it’s name and it’s located near the Harddisk and the power-supply part of the VU+ Duo.

When I looked at the capacitor it did not seem to be faulty or anything. So without the right tools to measure I’ve decided to just give it a shot and replace the original 16V 220uF 85 degrees celsius capacitor with a 105 degrees celsius 16V 330uF one.

In my case I’ve taken out the board, to have a little bit of extra space, and cut of the old capacitor. Desoldering would be nicer looking but, well …

Replacing it on the left-over pins of the old capacitor was a matter of seconds.

After putting the board back in, the VU+ Duo powered up and booted as new. Brilliant!

No Comments

Next step: Holodeck.

“The Infinadeck is the world’s first affordable omnidirectional treadmill that is designed to work both in augmented and virtual reality.  This revolutionary device provides the missing link making it now possible to have a true Holodeck experience. You might say, “Reality just got bigger”.”

Source: http://www.infinadeck.com/

No Comments

Nitrous – full IDE in your browser – with Collaboration!

“Nitrous is a backend development platform which helps software developers save time by cutting out the repetitive parts of creating development environments and automating them.

Once you create your first development environment, there are many features which will make development easier.”

Bildschirmfoto 2014-07-06 um 11.38.49

So what you’re getting is:

  • a virtual machine operated for you and set-up with a single click
  • A full-featured IDE in your browser
  • Code-Collaboration by inviting others to edit your project
  • a debugging environment in which you can test-run and work with your code

Here are some screenshots to get you a feel for it:

Source: https://www.nitrous.io/

No Comments

Boblight Alternative: Hyperion

After setting up Boblight on two TVs in the house – one with 50 and one with 100 LEDs – I’ve used it for the last 5 months on a daily basis almost.

First of all now every screen that does not come with “added color-context” on the wall seems off. It feels like something is missing. Second of all it has made watching movies in a dark room much more enjoyable.

The only concerning factor of the past months was that the RaspberryPi does not come with a lot of computational horse-power and thus it has been operating at it’s limits all the time. With 95-99% CPU usage there’s not a lot of headroom for unexpected bitrate spikes and what-have-you.

So from time to time the Pis where struggling. With 10% CPU usage for the 50 LEDs and 19% CPU usage for the 100 LEDs set-up there was just not enough CPU power for some movies or TV streams in Full-HD.

Hyperion

So since even overclocking only slightly improved the problem of Boblight using up the precious CPU cycles for a fancy light-show I started looking around for alternatives.

“Hyperion is an opensource ‘AmbiLight’ implementation controlled using the RaspBerry Pi running Raspbmc. The main features of Hyperion are:

  • Low CPU load. For a led string of 50 leds the CPU usage will typically be below 1.5% on a non-overclocked Pi.
  • Json interface which allows easy integration into scripts.
  • A command line utility allows easy testing and configuration of the color transforms (Transformation settings are not preserved over a restart at the moment…).
  • Priority channels are not coupled to a specific led data provider which means that a provider can post led data and leave without the need to maintain a connection to Hyperion. This is ideal for a remote application (like our Android app).
  • HyperCon. A tool which helps generate a Hyperion configuration file.
  • XBMC-checker which checks the playing status of XBMC and decides whether or not to capture the screen.
  • Black border detector.
  • A scriptable effect engine.
  • Generic software architecture to support new devices and new algorithms easily.

More information can be found on the wiki or the Hyperion topic on the Raspbmc forum.”

Especially the Low CPU load did raise interest in my side.

Setting Hyperion up is easy if you just follow the very straight-forward Installation Guide. On Raspbmc the set-up took me 2 minutes at most.

If you got everything set-up on the Pi you need to generate a configuration file. It’s a nice JSON formatted config file that you do not need to create on your own – Hyperion has a nice configuration tool. Hypercon:

Screen Shot 2014-06-28 at 08.52.51

So after 2 more minutes the whole thing was set-up and running. Another 15 minutes of tweaking here and there and Hyperion replaced Boblight entirely.

What have I found so far?

  1. Hyperions network interfaces are much more controllable than those from Boblight. You can use remote clients like on iPhone / Android to set colors and/or patterns.
  2. It’s got effects for screen-saving / mood-lighting!
  3. It really just uses a lot less CPU resources. Instead of 19% CPU usage for 100 LEDs it’s down to 3-4%. That’s what I call a major improvement
  4. The processing filters that you can add really add value. Smoothing everything so that you do not get bright flashed when content flashes on-screen is easy to do and really helps with the experience.

All in all Hyperion is a recommended replacement for boblight. I would not want to switch back.

Source 1: Setting up Boblight
Source 2: https://github.com/tvdzwan/hyperion/wiki/Installation

No Comments

ZFS Tutorial

“ZFS is really the final word in filesystems. With a feature set longer than this tutorial, it can take a while to master. You can set many more options per dataset, enable disk usage quotes and much more. Once you’ve used it and seen the benefits, you’ll probably never want to use anything else. Hopefully this has been helpful to get you on your way to becoming a FreeBSD ZFS master.”

Source: http://www.bsdnow.tv/tutorials/zfs

No Comments

setting up boblight with a Raspberry Pi and RaspBMC

Some might know AmbiLight – a great invention by Philips that projects colored light around a TV screen based upon the contents shown. It’s a great addition to a TV but naturally only available with Philips TV sets.

Not anymore. There are several open-source projects that allow you to build your very own AmbiLight clone. I’ve built one using a 50-LEDs WS2801 stripe, a 5V/10A power supply, a RaspberryPi, and the BobLight integration in RaspBMC (this is a nice XBMC distribution for the Pi).

Boblight is a collection of tools for driving lights connected to an external controller.

Its main purpose is to create light effects from an external input, such as a video stream (desktop capture, video player, tv card), an audio stream (jack, alsa), or user input (lirc, http). Boblight uses a client/server model, where clients are responsible for translating an external input to light data, and boblightd is responsible for translating the light data into commands for external light controllers.”

The hardware to start with looks like this:

pre_requisites

I’ve fitted some heat-sinks to the Pi since the additional load of controlling 50 LEDs will add a little bit of additional CPU usage which is desperately needed when playing Full HD High-Bitrate content.

The puzzle pieces need to be put together as described by the very good AdaFruit diagram:

diagramAs you can see the Pi is powered directly through the GPIO pins. You’re not going to use the MicroUSB or the USB ports to power the Pi. It’s important that you keep the cables between the Pi and the LEDs as short as possible. When I added longer / unshielded cables everything went flickering. You do not want that – so short cables it is 🙂

leds

When you look at aboves picture closely you will find a CO and DO on the PCB of the LED. on the other side of the PCB there’s a CI and DI. Guess what: That means Clock IN and Clock OUT and Data IN and Data OUT. Don’t be mistaken by the adapter cables the LED stripes comes with. My Output socket looked damn close to something I thought was an Input socket. If nothing seems to work on the first trials – you’re holding it wrong! Don’t let the adapters fitted by the manufacturer mislead you.

Depending on the manufacturer of your particular LED stripe there are layouts different from the above image possible. Since RaspBMC is bundled with Boblight already you want to use something that is compatible with Boblight. Something that allows Boblight to control each LED in color and brightness separately.

I opted for WS2801 equipped LEDs. This pretty much means that each LED sits on it’s own WS2801 chip and that chip takes commands for color and brightness. There are other options as well – I hear that LDP8806 chips also work with Boblight.

My power supply got a little big to beefy – 10 Amps is plenty. I originally planned to have 100 LEDs on that single TV. Each LED at full white brightness would consume 60mA  – which brings us to 6Amps for a 100 – add to that the 2 Amps for the PI and you’re at 8A. So 10A was the choice.

To connect to the Pi GPIO Pins I used simple jumper wires. After a little bit of boblightd compilation on a vanilla Raspbian SD card (how-to here). Please note that with current RaspBMC versions you do not need to compile Boblight yourself – I’ve just taken for debugging purposes as clean Raspbian Image and compiled it myself to do some boblight-constant tests. Boblight-constant is a tool that comes with Boblight which allows you to set all LEDs to one color.

If everything is right, it should look like this:

working_first_timeNow everything depends on how your LED stripes look like and how your TVs backside looks like. I wanted to fit my setup to a 42″ Samsung TV. This one already is fitted with a Ultra-Slim Wall mount which makes it pretty much sitting flat on the wall like a picture. I wanted the LEDs to sit right on the TVs back and I figured that cable channels when cut would do the job pretty nicely.

To get RaspBMC working with your setup the only things you need to do are:

  1. Enable Boblight support in the Applications / RaspBMC tool
  2. Login to your RaspBMC Pi through SSH with the user pi password raspberry and copy your boblight.conf file to /etc/boblight.conf.

The configuration file can be obtained from the various tutorials that deal with the boblight configuration. You can choose the hard way to create a configuration or a rather easy one by using the boblight configuration tool.

I’ve used the tool 🙂

Boblight Config ToolNow if everything went right you don’t have flickering, the TV is on the wall and you can watch movies and what-not with beautiful light effects around your TV screen. If you need to test your set-up to tweak it a bit more, go with this or this.

result_1

Source 1: http://en.wikipedia.org/wiki/Ambilight
Source 2: http://www.raspberrypi.org/
Source 3: https://code.google.com/p/boblight/
Source 4: http://www.raspbmc.com/
Source 5: http://learn.adafruit.com/light-painting-with-raspberry-pi/hardware
Source 6: How-To-Compile-Boblight
Source 7: Boblight Config Generator
Source 8: Boblight Windows Config Creation Tool
Source 9: Test-Video 1
Source 10: Test-Video 2

No Comments

Instruction-less computing: Doing stuff with a CPU without actually executing instructions

Having fun with hardware is a good way to learn about the machines which soon will become our new overlords. With this pretty interesting presentation you can dive deep into what a CPU does and how it can be exploited to run code by not running it.

Trust Analysis, i.e. determining that a system will not execute some class of computations, typically assumes that all computation is captured by an instruction trace. We show that powerful computation on x86 processors is possible without executing any CPU instructions. We demonstrate a Turing-complete execution environment driven solely by the IA32 architecture’s interrupt handling and memory translation tables, in which the processor is trapped in a series of page faults and double faults, without ever successfully dispatching any instructions. The “hard-wired” logic of handling these faults is used to perform arithmetic and logic primitives, as well as memory reads and writes. This mechanism can also perform branches and loops if the memory is set up and mapped just right. We discuss the lessons of this execution model for future trustworthy architectures.

Bildschirmfoto 2013-11-02 um 01.04.31

Source 1: https://www.usenix.org/conference/woot13/page-fault-weird-machine-lessons-instruction-less-computation

No Comments

when DVB-T is not interesting, use the hardware for fun and SDR!

SDR – or Software Defined Radio is relatively cheap and fun way to dive deeper into radio communication.

“Software-defined radio (SDR) is a radio communication system where components that have been typically implemented in hardware (e.g. mixers, filters, amplifiers, modulators/demodulators, detectors, etc.) are instead implemented by means of software on a personal computer or embedded system. While the concept of SDR is not new, the rapidly evolving capabilities of digital electronics render practical many processes which used to be only theoretically possible.” (Wikipedia)

So with cheap hardware it’s possible to receive radio transmissions on all sorts of frequencies and modulations. Since everything after the actual “receiving stuff”-phase happens in software the things you can do are sort of limitless.

Now what about the relatively cheap factor? – The hardware you’re going to need to start with this is a DVB-T USB stick widely available for about 25 Euro. The important feature you’re going to look for is that it comes with a Realtek RTL2832U chip.

“The RTL2832U is a high-performance DVB-T COFDM demodulator that supports a USB 2.0 interface. The RTL2832U complies with NorDig Unified 1.0.3, D-Book 5.0, and EN300 744 (ETSI Specification). It supports 2K or 8K mode with 6, 7, and 8MHz bandwidth. Modulation parameters, e.g., code rate, and guard interval, are automatically detected.

The RTL2832U supports tuners at IF (Intermediate Frequency, 36.125MHz), low-IF (4.57MHz), or Zero-IF output using a 28.8MHz crystal, and includes FM/DAB/DAB+ Radio Support. Embedded with an advanced ADC (Analog-to-Digital Converter), the RTL2832U features high stability in portable reception.” (RealTek)

You’ll find this chip in all sorts of cheap DVB-T USB sticks like this one:

3948543_b6f7670bc7To use the hardware directly you can use open source software which comes pre-packaged with several important/widely used demodulator moduls like AM/FM. Gqrx SDR is available for all sorts of operating systems and comes with a nice user interface to control your SDR hardware.

The neat idea about SDR is that you, depending on the capabilities of your SDR hardware, are not only tuned into one specific frequency but a whole spectrum several Mhz wide. With my device I get roughly a full 2 Mhz wide spectrum out of the device allowing me to see several FM stations on one spectrum diagram and tune into them individually using the demodulators:

Bildschirmfoto 2013-11-01 um 23.28.56The above screenshot shows the OS X version of Gqrx tuned into an FM station. You can clearly see the 3 stations that I can receive in that Mhz range. One very strong signal, one very weak and one sort of in the middle. By just clicking there the SDR tool decodes this portion of the data stream / spectrum and you can listen to a FM radio station.

Of course – since those DVB-T sticks come with a wide spectrum useable – mine comes with an Elonics E4000 tuner which allows me to receive – more or less useable – 53 Mhz to 2188 Mhz (with a gap from 1095 to 1248 Mhz).

Whatever your hardware can do can be tested by using the rtl_test tool:

root@berry:~# rtl_test -t
Found 1 device(s):
0:  Terratec T Stick PLUS

Using device 0: Terratec T Stick PLUS
Found Elonics E4000 tuner
Supported gain values (14): -1.0 1.5 4.0 6.5 9.0 11.5 14.0 16.5 19.0 21.5 24.0 29.0 34.0 42.0
Benchmarking E4000 PLL…
[E4K] PLL not locked for 52000000 Hz!
[E4K] PLL not locked for 2189000000 Hz!
[E4K] PLL not locked for 1095000000 Hz!
[E4K] PLL not locked for 1248000000 Hz!
E4K range: 53 to 2188 MHz
E4K L-band gap: 1095 to 1248 MHz

Interestingly when you plug the USB stick into an Raspberry Pi and you follow some instructions you can use the Raspberry Pi as an SDR server allowing you to place it on the attic while still sitting comfortably at your computer downstairs to have better reception.

If you want to upgrade your experience with more professional hardware – and in fact if you got a sender license – you can take a look at the HackRF project which currently is creating a highly sophisticated SDR hardware+software solution:

jawbreaker-fd0-145436

Source 1: http://www.realtek.com.tw/products/productsView.aspx?Langid=1&PFid=35&Level=4&Conn=3&ProdID=257
Source 2: http://gqrx.dk/
Source 3: www.hamradioscience.com/raspberry-pi-as-remote-server-for-rtl2832u-sdr/
Source 4: http://ossmann.blogspot.de/2012/06/introducing-hackrf.html
Source 5: https://github.com/mossmann/hackrf

No Comments

the Panic Status Board is here!

Last year in June I wrote about the concept of a ubiquitous status display of the business in every office. Especially for development and operations it’s pretty important to have important measurements, status codes and project information in front of them all the time.

Back then I already wrote about the Panic status board which gives a great looking example of a status display. Now there is a software from the company Panic which offers anyone the ability to create such a status board. It’s for iOS and looks awesome!

Bildschirmfoto 2013-05-04 um 19.56.56

Source 1: Mirror, Mirror on the wallSource 2: http://panic.com/statusboard/

No Comments

my home is my castle – CastleOS: the home automation operating system

And once again some smart people put their heads together and came up with something that will revolutionize your world. Well it’s ‘just’ home automation but indeed it looks very very promising. Especially the human-machine interface through speech recognition. First of all let’s start with a short introductory video:

“CastleOS is an integrated software suite for controlling the automation equipment in your home – an operating system for your castle, if you will. The first piece of the suite is what we call the “Core Service” – it acts as the central controller for the whole system. This runs on any relatively recent Windows computer (or more specifically, the computer that has an Insteon PLM or USB stick plugged in to it), and creates a network connection to both your home automation devices, and the second piece of the integrated suite – the remote access apps like the HTML5 app, Kinect voice control app, and future Android/iOS apps.” (from the CastleOS page)

So it’s said to be an all-in-one system that controls power-outlets and devices through it’s core service and offering the option to add Kinect based speech recognition to say things like “Computer, Lights!”.

Unfortunately it comes with quite high and hard requirements when it comes to hardware it’s compatible with. A kinect possible exists in your household but I doubt that you got the Insteon hardware to control out devices with.

That seems to be the main problem of all current home automation solutions – you just have to have the according hardware to use them. It’s not quite possible to use anything and everything in a standardized way. Maybe it’s time to have a “home plug’n’play” specification set-up for all hard- and software vendors to follow?

Source 1: http://www.castleos.com

1 Comment

h.a.c.s. html5 user interface re-implemented

Slow is the right word to describe my html and javascript learning-by-doing progress right now. I have chosen the h.a.c.s. user interface as a valid project to learn html and javascript up to a point where I can start to write useable websites with it. The h.a.c.s. ui seemed to be a good choice because it’s at the moment only used by my family and they are a bunch of battle-proven beta testers.

So first a small video to get an idea what I am implementing right now:

So all you can see is SVG and HTML rendered stuff – made with the help of awesome javascript libraries, as there are:

  • jQuery
    • for the basic javascript coverage
  • Raphaël
    • to draw svg in a human-controllable
  • JustGage
    • to draw those nice gauges
  • OdoMeter
    • an animated HTML5 canvas odometer

I plan to add a lot more – like for swiping gestures. So this will be – just like h.a.c.s – a continuous project. Since I switched to OS X entirely at home I use the great Coda2 to write and debug the code. It helps a lot to have two browser set-up because for some reason I still not feel that well with the WebKit Web Inspector.

Bildschirmfoto 2013-01-06 um 20.47.22

Another great feature of Coda2 is the AirPreview – which means it will preview your current page in the editor on an iOS device running DietCoda – oh how I love those automations.

So I reached the first goal set for myself for the user interface: It’s doing the things the old UI did and it’s maintainable in addition. I am still struggling with javascript here and there – mainly because the debugging and tracing is oh-so-difficult (or I am to slow understanding).

If you got any recommendation for a javascript editor that can handle multiple includes and debugging (step-by-step, …) and good tracing for events please comment!

Source 1: jQuery
Source 2: Raphaël
Source 3: JustGage
Source 4: OdoMeter

No Comments

know your numbers!

Wikipedia describes latency this way:

“Latency is a measure of time delay experienced in a system, the precise definition of which depends on the system and the time being measured. In communications, the lower limit of latency is determined by the medium being used for communications. In reliable two-way communication systems, latency limits the maximum rate that information can be transmitted, as there is often a limit on the amount of information that is “in-flight” at any one moment. In the field of human-machine interaction, perceptible latency has a strong effect on user satisfaction and usability.” (Wikipedia)

Given that it’s quite important for any developer to know his numbers. Since latency has a huge impact on how software should be architected it’s important to keep that in mind:



Bildschirmfoto 2012-12-25 um 21.28.20



Source: http://www.eecs.berkeley.edu/~rcs/research/interactive_latency.html

No Comments

Mount Hard Drive #2

So after I wrote about the great fileserver expansion plans I thought I give a short update on the progress:

IMG_2054 Bildschirmfoto 2012-12-13 um 20.55.57

Bildschirmfoto 2012-12-13 um 22.16.33



No Comments

being there, without being there: Good Night Lamp

Isn’t technology great when it brings families closer together, even when they are thousand miles apart?

Home automation does not only mean that you are going to flip some switches and sensor away in every imaginable way. It also means creativity. And being creative with the functionalities at hand is really what makes home automation so interesting.

It’s those creative ways that adds use to the nerdy home automation switches and sensors. It’s what adds practicality.

Good Night Lamp is such a creative solution that makes use of home automation hardware and the internet. To understand the concept, watch a video:

“The Good Night Lamp is a family of connected lamps that lets you communicate the act of coming back home to your loved ones, remotely.”

Well I don’t know if it really needs specialized hardware like those Good Night Lamp products. But certainly if you have some sensory and the ability to flip switches it is fairly easy to come up with workflows and things that should happen when the circumstances are right. In fact I do not believe in highly specialized products like a single-purpose lamp. But I do believe, if those lamps are connected to a network and if you can access them through some sort of API, that those types of products will pave the way to a connected world we only know from science fiction yet.

Another good solution to this is the long promised IP capable light bulb. Engineers were using the “light bulb with an ip adress” as an example for IPv6 for years now. And it seems that the time has come when we really want to assign an ip adress to every lightbulb in our home.

LIFX is a good start concept and in a couple of months there will be more manufacturers who are offering networked light bulb solutions.



Source 1: http://goodnightlamp.com/
Source 2: http://lifx.co/

No Comments

Raspberry Pi gets a camera

The first signs of the upcoming camera board for the raspberry pi are showing. During the Electronica 2012 fair RS showed the board to the public for the first time.

Since it’s going to be a 25 Euro add-on for the Pi the specification is quite impressive. The OmniVision OV5647 is used as the Image Sensor – it’s bigger brother is used in iPhone 4. OmniVision says:

“The OV5647 is OmniVision’s first 5-megapixel CMOS image sensor built on proprietary 1.4-micron OmniBSI™ backside illumination pixel architecture. OmniBSI enables the OV5647 to deliver 5-megapixel photography and high frame rate 720p/60 high-definition (HD) video capture in an industry standard camera module size of 8.5 x 8.5 x ≤5 mm, making it an ideal solution for the main stream mobile phone market.

The superior pixel performance of the OV5647 enables 720p and 1080p HD video at 30 fps with complete user control over formatting and output data transfer. Additionally, the 720p/60 HD video is captured in full field of view (FOV) with 2 x 2 binning to double the sensitivity and improve SNR. The post binning re-sampling filter helps minimize spatial and aliasing artifacts to provide superior image quality.

OmniBSI technology offers significant performance benefits over front-side illumination technology, such as increased sensitivity per unit area, improved quantum efficiency, reduced crosstalk and photo response non-uniformity, which all contribute to significant improvements in image quality and color reproduction. Additionally, OmniVision CMOS image sensors use proprietary sensor technology to improve image quality by reducing or eliminating common lighting/electrical sources of image contamination, such as fixed pattern noise and smearing to produce a clean, fully stable color image.

The low power OV5647 supports a digital video parallel port or high-speed two-lane MIPI interface, and provides full frame, windowed or binned 10-bit images in RAW RGB format. It offers all required automatic image control functions, including automatic exposure control, automatic white balance, automatic band filter, automatic 50/60 Hz luminance detection, and automatic black level calibration.”

That sensor delivers RAW RGB Imagery to the RaspberryPi through the onboard camera connector interface:

this actually is a 14 MPixel test-board and not the final 5 MPixel one…

And the part that impressed me the most is that that 5 Megapixel sensor delivers it’s raw data stream and it gets h264 compressed directly within the GPU of the Raspberry Pi. 30 frames per second 1080p without noticeable CPU load – how does that sound? – Not bad for a 50 Euro setup!

Source 1: First Demo
Source 2: OmniVision OV5647 Color CMOS QSXGA Image Sensor

No Comments

extending the house storage

In times when mobile phone cameras produce pictures of 2 MBytes each and decent DSLR cameras produce pictures in the range of more than 20 Mbytes each – not speaking of the various sensors around the house the question of how all of this is going to be stored is an interesting one.

Prices for mass storage is dropping for years and sized of hard disks are getting bigger and bigger. 3 Tbyte drives are fairly cheap now. Cheap enough to consider serious redundancy even for home use.

Having that home automation hobby and having very specific needs when it comes to home entertainment or even watching TV (we don’t watch live-tv…) we have a relatively huge demand for storage space. That way we are already storing over 10 Tbyte of data, fully encrypted, redundant and backed-up.

Our file server infrastructure grew with the needs over the years.

It started way back in 2003 when I set-up the first fileserver for my apartment back then. It was a fairly huge 19 inch case with 5 hard disks (100 Gbyte each). This machine was filled in 2005 and needed replacement.

We’re in IDE land back then. Because the system hardware died on me due to a power surge all the disks and a new mainboard were seated in a new case with room for a lot of disks.

One interesting detail might be that I consistently used Windows Server for that purpose.

The machine always wasn’t just a fileserver. It was smtp, imap, nntp and media server all the time. That lead to a growing demand of CPU and memory resources. It started with an 800 Mhz AMD Athlon (which died quickly) and for the next years to come I used a 2.8 Ghz Intel Pentium 4. Everything started with Windows Server 2003 – bought in the Microsoft Store when I was a Microsoft employee.

Diskspace demand kept growing and in 2009 a new case, new mainboard + memory and new disks where due.

Since 2009 a Core4Quad Q9550 with 2.8 Ghz and 16 Gbyte of Memory is the heart of our fileserver. Since we’re frequently live-transcoding video streams to feed iPads and iPhones around the house that machine has plenty of grunt to feed the demand. We can have 2 iPhones and 2 iPads playing 720p content without getting stutters. Back in 2009 we also switched to a mixed IDE and SATA setup as you can see in the picture:

Plenty of room when the new case arrived – it was getting crowded just 2 years later in 2011. Every seat was taken – which means 13 disks are in that case and 1 attached through USB.

That adds up to more than 16 Tbyte of raw storage. In 2011 we also upgraded to Windows Server 2008. We never lost a bit with that operating system, not under the heaviest load and even through serious hardware malfunctions. A lot of disks of those 13 died throughout the years: Almost 1 every 2 months was replaced – most of them through extended waranties – of course we have a spare always ready to take the place. Only one time I had to rush to a store to get a replacement drive when two disks failed short after each other. That’s why there’s that 2 Tbyte drive in the 1.5 Tbyte compound…

So it’s getting full again. Since that case isn’t really holding more disks and replacing them is getting harder because of the tight fit the idea was born to now add a bigger case but to just add a NAS/SAN which holds between 6 to 8 disks at once, comes with it’s own redundancy management and exports one big iSCSI volume.

That said a network card was added to the fileserver and a QNAP TS-859 Pro+ 8-bay appliance was bought. This one is a shiny black device which uses less power then an aditional case with extra cpu and memory would have use and after calculating through a number of combinations it’s even the cheapest solution for an 8 drive set-up.

After some intensive testing it seems that the iSCSI approach is the most robust one. Since I am just done with testing the appliance the next step is to buy drives. So stay tuned!

Source 1: http://www.qnap.com/de/index.php?lang=de&sn=375&c=292&sc=528&t=532&n=3486

4 Comments

when the pi gets a case…

Finally another Raspberry Pi with two brand new cases arrived. Finally I’ve got a case for two of my PIs – hurray!

Update: Andreas salso got his pi and case – he has more pictures.

No Comments

baking with the PI

Do you know what happens during the push of the power button and typing your log-in information inside of your computer? No? You should. At least from a software side. Not that it is necessary to use a computer. But in order to understand what this wonderful machine does and why.

For those teaching and learning purposes the Raspberry Pi is a perfect device. It’s cheap and now there is a course you can take online which shows you – starting from the very beginning – how to get the device up and running and how to make it do what you like. And that’s without installing an operating system. You are about to write your very own.

“This website is here to guide you through the process of developing very basic operating systems on the Raspberry Pi! This website is aimed at people aged 16 and upwards, although younger readers may still find some of it accessible, particularly with assistance. More lessons may be added to this course in time.”

Source: http://www.cl.cam.ac.uk/freshers/raspberrypi/tutorials/os/

No Comments

das Keyboard

It appeared to me that I stopped working with a decent keyboard since I moved completely to Macs at home. I was using the keyboards the machine came with and not always does Apple deliver the best possible keyboard for the money.

So I tried to turn back to my trusty IBM PS/2 Model M last week and I had to find out that somehow the actively powered USB to PS2 adapter I had is got lost. A passive one just doesn’t cut it and the keyboard does not work at all.

I remembered that in 2006 I wrote about a back-then-new keyboard that resembled the fantastic Model M. Voilá! They even worked on their keyboards since 2006 and improved them 🙂

A little bit more than 6 years after writing first about the product I got me a “das Keyboard Ultimate S EU”.

First verdict: It is awesome!

It’s expensive, that’s true. But if just feels right typing on it. I can see me writing a lot of stuff for longer periods on that keyboard 🙂

Source 1: http://www.schrankmonster.de/2005/05/22/real-elite-keyboard
Source 2: http://www.schrankmonster.de/2005/08/17/teh-keyboard-for-teh-coders/



2 Comments

a delicious raspberry pi

Just a couple of days ago – after a waiting time of more than half a year – my personal raspberry pi board arrived. Fantastic!

It’s small. Oh yes, it’s very very small.

What is the Raspberry Pi you may ask:

“The Raspberry Pi is a credit-card sized computer that plugs into your TV and a keyboard. It’s a capable little PC which can be used for many of the things that your desktop PC does, like spreadsheets, word-processing and games. It also plays high-definition video. We want to see it being used by kids all over the world to learn programming.”

For under 40 Euro you get a huge choice of I/O interfaces like USB, Ethernet, HDMI, Audio and Multi Purpose IO pins you can play with if you’re into hardware hacking. This small card is running a fully blown linux and because it has a dedicated graphics core which can hardware decode and encode 1080p h264 it’s definitely a good choice for a home mediacenter (yes, XBMC runs on it.)

It draws so little power that you could use solar panels to power it. It’s all open and sourced and I will use it for a couple of things in the household. Like a cheap Airplay node. Or a more intelligent sensor node for home automation. This thing seriously rocks – finally a device to play with – with reasonable horse-power.

Source 1: http://www.raspberrypi.org
Source 2: http://www.raspbmc.com

1 Comment

Mirror, Mirror on the wall

There are many things which are underestimated when team leads think about their team and possible actions to drive progress.

One of those things is that a team needs information to maintain and gain velocity. You cannot expect everyone to know just out of the blue what is important and in which direction everything is moving. To let everyone know and to develop that direction it’s important to share information as much as possible. It’s important to give everyone access to the information necessary to make a better job.

That’s why we had a build monitor at sones. We had a tool that displayed the current status of our build servers to all developers. Everytime someone committed a change, those build servers got this commit, built it and tested it with automated tests. The status of that could be seen by all developers as things happened.

So within seconds everyone could see if his commit did break something. Even better: Everyone could see. Everyone cared that the build needed to be working, that tests needed to pass. It was everyones job to do the housekeeping. When we switched from Team Foundation Server to GIT and Jenkins this status display needed to be replaced – you could immediately tell that things went from good to not-so-good in terms of build stability and automated testing.

Today I had the opportunity to take a tour of the Thomann logistics center. Standing in the support department I had this in front of me:

There were like 6 big status screens displaying incoming call status of the day, sales figures and other statistics important to those who work there. It’s a very important and integrated way to keep information flowing.

Since I am with Rakuten I thought about having a new status board set-up for my team. Something that might be inspired by the awesome status board which panic has built:

Since in addition to sones there are a lot of more things to track and handle (code, deployment, operations, overall numbers) I think such a status board will be of invaluable worth for the team.

Source 1: http://www.panic.com/blog/2010/03/the-panic-status-board/

2 Comments

Boogie Board

Two weeks ago I had read an article about a “replacement for papernotes” product called “Boogie Board”. The company behind the product claims to replace paper with the bold slogan of “say goodby to paper”.

Well what is it? Basically it’s a liquid crystal display without the logic to adress specific pixels. So think of it like taking the liquid crystal part and leaving out all the transistors and logic to actually display something. Then add a pen or even your finger nail and you can “write” on that display – what’s happening is that obviously the crystals get pushed aside and the background of the “display” shines through – this background is white so when you write on the boogie board everything is white on black…

_MG_9156

_MG_9160

_MG_9162

The only button on the tablet is named “erase” – and that’s what the button does: the whole display flashes two times, one white, and then black and everything is back to where we started. You cannot save. You just press erase and start over. It’s truly a replacement for post-it-notes…

Of course there’s a battery inside, and it’s said to hold for tens of thousands of erases. You cannot change the battery when it’s empty, but on the other hand this gadget is less than 30 Euros and it does look like you can break it up and try your best to exchange the battery yourself. Since the battery isn’t needed to display anything I don’t think I will run out of juice just yet.

Source: http://www.improvelectronics.com

1 Comment

das außer-Haus Backup

Irgendwie werden es auch privat immer immer mehr Daten – mit immer zunehmender Geschwindigkeit… Alle paar Jahre tausche ich bei uns im Haushalt die Festplatten/Speicherlösung komplett aus – was zwar immer wieder mal eine Investitions bedeutet, gleichzeitig aber auch dafür sorgt dass Daten nicht irgendwelchen ungünstigen mechanischen, chemischen oder magnetischen Effekten zum Opfer fallen… Ja so etwa alle zwei Jahre wird alles einmal umkopiert… Das dauerte beim letzten Mal zwar gut eine Woche, aber naja so ist das eben…

Aus vielerlei Grund haben wir auch für einen Haushalt recht viel Bedarf an Speicherplatz – teilweise wohl auch weil meine Frau Photographin ist – aber ich als “werf-nix-weg”-Typ werd da auch einen guten Anteil dran haben…

Herr über alle unsere Festplatten (kein Witz, die Rechner bei uns haben ihre Festplatten eigentlich nur um booten zu können) ist seit jeher ein einzelner Rechner welcher ebenso alle paar Jahre komplett ausgetauscht wird. Dieser Rechner verwaltet im Moment zwischen 12-15 Festplatten verschiedener Größe – Hauptarbeit wird zur Zeit durch drei separate (gewachsene) RAID-5 Volumes erledigt…

Nebenbei: Nein ich kann/will da kein RAID-6 fahren ohne entweder Linux zu verwenden (was aus verschiedenen Gründen nicht geht) oder einen Hardware-Controller zu verwenden, was nach einschlägigen Erfahrungen querbeet durch alle möglichen Hardware RAID Controller ausfällt.

Dem ganzen Festplattenstapel liegt dann ein Standard-PC mit Windows Server 2008 zugrunde – zum einen weil ich so eine Lizenz noch herumliegen hatte und zum anderen weil ich in über 10 Jahren File-Server Erfahrungen sammeln noch nie auch nur ein Byte unter Windows verloren habe. Zusätzlich habe ich einen riesigen Haufen Software welche Windows-only ist ud sozusagen ständig laufen muss um Sinn zu machen (Mail-Server Puffer, Newsserver Mirror, Musik und Video Streaming Server, Medienbibliothek, Videorekorder,…

Diese drei großen RAID Volumes schnappt sich dann Truecrypt und ver- und entschlüsselt zuverlässig vor sich hin – im Endeffekt gibt es kein Byte Daten im Haushalt welches nicht verschlüsselt wäre. Gut für uns.

So ein RAID verhindert nun ja aber nicht dass dennoch oben genannte ungünstige Effekte eintreten und man mal eine oder mehrere Defekte zu beklagen hat. Im Normalfall tauscht man die defekte Festplatte, resynct das RAID und alles funktioniert weiter ohne dass man Daten verloren hätte. Allerdings ist das ja kein Backup. Das ist nur eine erste Absicherung gegen mögliche Defekte.

Getreu folgendem kurzen Musikstück:

RAID ist kein Backup

… ist ein RAID eben kein Backup. Backups erledigt bei mir eine Sammlung von Scripten welche jeweils in festen Abständen Vollbackups und Differenz-Backups erstellt. Da kommt dann ein Haufen 1 Gbyte großer Dateien raus welche dann anschliessend per RSync in mühevoller (und dank funktionierendem QoS unbemerkt) Arbeit außer Haus geschafft werden. Die Komplett-Backups dauern aufgrund der großen Menge einfach ewig lang und lassen sich recht einfach dadurch beschleunigen dass man sozusagen das Backup physisch auf einer externen Festplatte zum Server trägt…die Differenz-Backups sind dann meist immer recht flott durchgelaufen. Speicherplatz im Internet wird ja auch immer billiger und so haben wir auch immer ein gutes Off-Site Backup unserer Daten…

Für Windows gibt es neben den üblichen Cygwin Ports von rsync auch eine gute GUI Version namens DeltaCopy. Das Ding kopiert zuverlässig und auch wenn mal der DSL Router rebootet oder hängt nimmt er selbständig die Kopierarbeit wieder auf sobald Netz wieder verfügbar ist.

Damit DeltaCopy seine Daten irgendwo abladen kann wird auf der Gegenstelle natürlich ein rsync Server vorrausgesetzt. Die Konfiguration eines solchen ist nicht sonderlich kompliziert – im Grunde muss man nur rsync installieren und die rsyncd.conf Datei anpassen. Zusätzlich dazu muss man eine Konfigurationsdatei anlegen in welchem nach dem Schema “Benutzername:Passwort” entsprechend die Nutzeraccounts angegeben werden – das wars eigentlich schon. Rsync ist sehr robust und vor allem auch gut für geringere Bandbreiten geeignet. Wenn sich an einer Datei nur wenige Bytes geändert haben müssen auch nur die geänderten Bytes übertragen werden.

Source 1: http://www.speichergurke.de
Source 2: http://www.aboutmyip.com/AboutMyXApp/DeltaCopy.jsp
Source 3: http://de.wikipedia.org/wiki/Rsync

No Comments

I am a space ship captain. Not.

So finally after years and years of hope and nerdy ideas I am able to hold a tablet device in my own hands and it’s not only as good as Picards tablet was back in that great “Star Trek: Next Generation” series, it’s better.

IMG_0964

Of course I had to import that particular iPad from the U.S. (thanks Alex!) – actually it was the first time I imported something that expensive. Beside some fun with the shipping company everything went fine. Since Apple just announced to delay the launch of the iPad in Europe for a month it’s nice to have a gadget just a few weeks after it was available in the U.S.

No Comments

Want. To. Buy. :-)

Oh what a nice n3rd toy this would be. Rumors say it will be available soon for under $30. And for those who right now think: “What the hell is this?” – This is a coffee mug in the shape of a quite expensive canon lens. In fact I already heard of that idea more than a year ago and wrote about it here. At this time there were only hopes that it would be produced.

canonlensmug



Source: http://www.petapixel.com/2010/03/06/canon-lens-mug-purchased-in-canada/

2 Comments

expect podcasts from sones :-)

Since sones will be at some community events, conferences and trade shows this year we thought it might be a good idea to have some hardware to document these events.

Since we wanted to have video and we did not want to cope with the rather complex subject of DSLRs we bought a full-hd-camcorder.

IMG_4669 Panasonic HDC-SD300

IMG_4672Touchscreen… hard to find anything without a Touchscreen these days.

No Comments

what would you do with 1 million frames per second?

This is just beautiful:

No Comments

and another Dell laptop just died…

this time a XPS M1330 blue-screened and only shows colored lines if you restart it:

Foto

If only the hardware would be as great as their service is!

1 Comment

How to sell a car

Mission accomplished. I successfully talked a co-worker, who needed to buy a new car, into buying a gadget-packed BMW 1 series.

He calls it his “cluster on 4 wheels” – because obviously there is some processing “horse-power” in this machine 🙂

img_7539s

May he always have a safe ride!

Source 1: http://blog.ahzf.de/index.php/2009/09/21/mein-cluster-hat-vier-rader/

No Comments

APC PowerChute Business Edition and VMware Server…

I’ve run into several problems while trying to install the current 8.1 version of the APC PowerChute Business Edition.

Basically I get this error message when I am trying to install it:

powerchute-novmware

So you can simply not install this version of PowerChute on this machine – OR you could go here and follow the link to the Download of the 8.0 version of the software. This will start the setup with this screen:

powerchute-novmware2

Great! Just get the “old” version and use it.

Source 1: APC PowerChute and VMWare

No Comments

In case of low performance: check your systems latency

I ran into some strange problems with a notebook that leaded to sound drop-outs or things like sluggish UI and HDD performance. So I tried almost everything troubleshootig the problem. That worked for some problems but there are occasions when I want to have a more systematic approach to those kinds of hardware / driver related problems.

One tool that can help to find hardware / driver problems is the DPC Latency Checker. This tool measures and displays the latency of your system. All you have to do is watch as the measurements scroll by and remove / disable one device after another from your machine. As soon as the latency turns green again there’s a high probability that the device you removed last has a problem of some kind.

dpclatency

On my machine everything is in the greens now – after some BIOS and driver updates. If your system has some issues you would see something like that:

cdrom
(courtesy of Gnawgnu’s Realm)

Source 1: http://www.thesycon.de/deu/latency_check.shtml
Source 2: http://gnawgnu.blogspot.com/2009/01/dell-latitude-e6400-sound-problem-fixed.html

No Comments

Up-Grayed

Last week I upgraded my iPod touch to an iPhone… well actually I got a new iPhone 3GS aside the iPod.

IMG_7392

It’s a fast device – even noticeably faster than the 2nd gen iPod Touch. It’s got almost the same battery life like the touch for me and it was a plug-and-play experience to use it the first time.

What I wasn’t expecting is that the smooth experience suddenly came to a stop when I tried to plug the iPhone into my car – just where the iPod touch did the job for about 5 months (including that the touch got charged by the car along the way).

With the iPhone I got two error messages simultaneously:

IMG_0010

“Charging not supported by this accessory”

IMG_0009

“This accessory is not supported by iPhone”

Damn you Apple! What’s the problem? There’s a standard USB port which powered 2,5 inch hard disk drives previously and the iPhone just states that it cannot be charged with this accessory (e.g. the car).

On the other hand everything else just works as it was working with the iPod. I can browse my music library on the iDrive I can listen to music – everything works, beside those two error messages and the not-charging iPhone. Thank you Apple B-) Maybe I need to up-grayed my car too?

2 Comments

massive parallel computing with FPGAs

Today we had a great meeting with SciEngines. These guys offer a great platform for everything that needs massive parallelism and IO bandwidth scalability. They even brought a small copacobana cluster to our headquater.

IMG_0045

IMG_0044

Source 1: http://www.sciengines.com
Source 2: http://www.sciengines.com/products/computers-and-clusters/copacobana-s3-1000.html

No Comments

Canon 50mm f/1.8 II lens arrived

Today the new lens for our Canon DSLR arrived – just in time when we need it. Hopefully the polarizing filters will arrive also this week.

Behold the beauty of the first picture! *narf*… Awwww

IMG_7504

IMG_7524

IMG_7527

No Comments

That’s what I call customer support

One of our two DSL lines in the office is provided by QSC. So far the decision to go with QSC was one of the best since I deal with Internet providers. These guys at QSC are just brilliant. Great support, great service, great pricing!

They even sent me a notice that there will be a planned maintenance downtime in more than a week. They do the maintenance on a saturday morning. When it’s unlikely that anyone will miss the uplink. (Since we got two, we won’t actually miss it… it’s just slower)

qscroxx

No Comments

there goes another Dell Latitude D630

I always asked myself when this particular notebook will fail. Almost everybody I know who got this notebook got his mainboard replaced in the last year. Now it seems that it’s time for my Latitude to get a new set of chips.

It crashed while I was using it and since that it only boots up like this:

IMG_4432

Oh I looked up which graphic chip that actually is. It’s a NVidia NVS135 chip – not like I thought the NVS160 which is embedded in my current generation latitude. Thank god I got 3 year repair and replacement….

4 Comments

The Samsung UE46B6000 + Apple Mac Mini + Plex

So it’s been some days with the new Mediacenter Setup. And all I can say is: Oh boy that is some serious cool setup. I wouldn’t want to chance anything beside adding a new Sound System (>5.1 FTW!).

The Display itself is thinner than thought:

IMG_5394

I strongly recommend the Mac + Plex + Full HD display setup. Even if you don’t get any HD content from your cable provider you can live-stream or download HD content through the different provider plugins inside Plex. The plugin infrastructure with the built-in “App Store” is just great.

Since Plex is a XBMC based Mediacenter software you have tons of information scrapers regarding series and movies. So you’re eventually huge collection gets indexed and presented in a way you would not get from any other Mediacenter. You get pictures, movie posters, descriptions and many more just by automatic indexing your collection.

IMG_5404_2

MST3k FTW!

Needless to say that HD content is something different. I only had some HD content on normal computer displays in the last years – having it now huge and sharp is different – better.

BTW: It’s on the floor right now because my wife couldn’t decide until now which tv-stand would suffice…

Source 1: http://av.samsung.de/produkte/detail2_main.aspx?guid=b6c1306c-f57d-4ce7-a944-56cc7346ed2e
Source 2: http://www.apple.com/macmini/
Source 3: http://plexapp.com/

8 Comments

new tv set arrived

Finally we got a TV set. Since Samsung announced new LED based sets we ordered a 46 inch tv. It was delivered today (yesterday the Mac mini which will drive the mediacenter arrived). I only had a short test-run scanning for cable stations… so more of that in the following days – especially more of the mediacenter configuration.

IMG_5325

Source: Samsung UE46B6000

2 Comments
