Head Up Display esthetics

Many cars these days come with head up displays. These kind of displays are used to make information like the current speed appear “floating” over the street ahead right in your field of vision.

This has the clear advantage that the driver can stay focused on the street rather than looking away from the street and to the speedometer.

As practical as it seems these displays are not easy to build and seemingly not easy to design. Every time I came across one it’s built-in functionalities where limited in a way that I only can assume not a lot of thought had gone into what exactly would the driver like to see and how that would be displayed. There was always so much left to desire.

Apparently the technology behind these HUDs is at a point where it’s quite affordable to start playing with some ideas to retrofit a car with a more personal and likeable version.

So I started to take a look at what is available – smart phones have bright displays and I had never tried to see what happens when you try to utilize them to project information into the windshield. So I tried.

As you can see – bright enough, readable but hazy and not perfectly sharp. The reason is quite simple:

“In the special windshield normally used, the transparent plastic safety material sandwiched in between the two pieces of glass must have a slight and very precise wedge, so that the vehicle operator does not see a HUD double image.”

laserfocusworld

There are some retrofit adhesive film solutions available that claim to help with that. I have not tried any yet. To be honest: to my eye the difference is noticeable but not a deal-breaker.

So I’ve tried apps available. They work. But they do a lot of things different from how I would have expected or done them. They are bearable, but I think it could be done better.

tldr: I started prototyping away and made a list of things that need to be done about the existing HUD applications.

mirrored basic html prototype, not well adjusted, just to play…

Here’s my list of what I want to achieve:

  • display orientation according to driving direction – I had expected all HUD applications to do this. They know the driving direction. They know how the device is oriented in space. They can tell which direction the windshield is. They know how to correctly turn the screen. They do not do that. None of them.
  • fonts and numbers – I cannot stand the numbers jumping around when they change up and down
  • speed steps interpolation – GPS only delivers a speed update every second or so. In this time speed might jump up and down by more than +1. The display has 60 fps and gyros to play with and interpolate… I want smooth number transitions.
  • have an “eco-meter” – using gyros the HUD would be able to display harsh accelleration and breaking. Maybe display a color-coded bar and whatever is measured is reflected in the bar going left or right…
  • speed-limit display – apparently this is a huge issue looking at the data availability. There seems to be open-street-map data and options to contribute. Maybe that can be added.
  • have a non-hud mode – non mirrored to use for example to set speed limits and contribute to OpenStreetMap this way!
  • automatically switch between HUD and non-HUD mode – because the device knows it’s orientation in space – if you pick it up from the dashboard and look into it, why not automatically switch?
  • speed zones color coding – change the color of the speed display depending on configurable speed regions. 0-80 is green, 80-130 is yellow, 130-250 is red.
  • turn display off when car stopped – if there’s nothing displayed or needs to be displayed, for example because the car stopped the display can be turned off completely on it’s own.

Navigation is of limited value as the only way I could think of adding value would be a serious AR solution that uses the whole windshield. Now I’ve got these small low-power projectors around… that get’s me thinking…

What would you want to have in such a HUD in your car?

reward driven speed limits

As you might know I am living in Germany. Germany is the one country where you have some roads that are legally not having any speed limit whatsoever. If the circumstances allow to safely drive 250 km/h you are allowed to do so. It’s up to the drivers judgement.

Now as much as this is a great thing of personal freedom it also has some negative side effects on the climate.

Your car is burning a lot more fuel when driving those kind of speeds. And a lot meaning that it resembles more an exponential curve than a linear line. Rule of thumb: 2x the speed is more than 4x the consumption.

Ever once in a while people start discussing about a general speed limit for Germany – as every other country has it. Some talk about 160 km/h, some about 120 km/h.

The motivations are diverse: climate, resource use, safety, …

In any case additional limits would need to be enforced. More speed traps…

A.Savin (Wikimedia Commons · WikiPhotoSpace)

What if things would be handled differently?

How about this:

Politics would introduce a “best speed lottery”. On every street without a speed limit there would randomly be speed controls and speed traps. Those who follow the best practices of driving … Let’s say 120 km/h… Would be rewarded when randomly photographed. The reward would be a tax discount on car tax and/or gas tax and one ticket put into the countries lottery pool. Once a quarter a new electric car or similar would be given to a random winner.

What would you think would make people drive slower in their own motivation?
